Type

Liquid-cooled, 12 valve, DOHC, inline 3-cylinder

Capacity

1160 cc

Bore

90 mm

Stroke

60,8 mm

Compression

13.2:1

Max Power EC

180 PS / 177.5 bhp (132.4 kW) @ 10,750 rpm

Max Power Horsepower

177,5 hp

Max Torque EC

125 Nm @ 9,000 rpm

Max Torque Newton

125 Nm

System

Multipoint sequential electronic fuel injection with electronic throttle control

Exhaust

Stainless steel 3 into 1 header system with underslung primary silencer and side mounted secondary silencer

Final Drive

X-ring chain

Clutch

Wet, multi-plate, slip and assist

Gearbox

6 speed

Frame

Aluminium twin spar frame, bolt-on aluminium rear subframe

Swingarm

Aluminium, single-sided

Front Wheel

Cast aluminium, 17 x 3.50 in

Rear Wheel

Cast aluminium, 17 x 6.00 in

Front Tyre

120/70 ZR 17

Rear Tyre

190/55 ZR 17

Front Suspension

Öhlins 43 mm NIX30 upside down forks with adjustable preload, rebound and compression damping, 120 mm travel.

Rear Suspension

Öhlins TTX36 twin tube monoshock with preload, rebound and compression damping, 120 mm rear wheel travel.

Front Brakes

Twin 320mm floating discs. Brembo Stylema monobloc calipers, OC-ABS, radial master cylinder with separate reservoir, span

Rear Brakes

Single 220mm disc. Brembo twin piston caliper, OC-ABS. Rear master cylinder with separate reservoir.

Instrument Display and Functions

Full-colour 5" TFT instruments

Width Handlebars

792 mm mm

Height Without Mirror

1089 mm mm

Seat Height

830 mm

Wheelbase

1445 mm mm

Rake

23,9 °

Trail

104,7 mm

Wet Weight

197 kg

Fuel Consumption

44.8mpg (6.3 l/100km)

Kilometers Per Liter

19 km/L

Service Interval

10,000 miles (16,000 km) /12 months service interval, whichever comes first
